Mondraker - LEADER 24 (KIDS)

MOND-B-Lead24-Blue20

  • Sale
  • Regular price $649.00
  • Will be in stock after


PLEASE CALL US AT 805-850-3200 TO PLACE YOUR ORDER


DESCRIPTION

NOTE:

Pre-orders only. Subject approval to availability and delivery times.

Please call us for availability and all other information at 805-850-3400.


Young bikers can now start a taste of mountain biking with Leader 24! This kids’ sports bike is packed with mountain bike features tailored towards children who want to get started on trail-shredding rides.


The Custolite alloy frame with an integrated headset and compact geometry helps with resistance and mobility for better speed and performance. Leader 24 comes with high-performance suspension that helps with stability and control by absorbing the strongest vibrations and keeping your wheels planted on the ground even on the bumpiest of the trails.


Leader 24 sports high-performance rear derailleurs and 24” tires, for ultimate precision and grip through uneven and rough trails. Young riders can conquer rigorous trails in the comfort of consistent and unstoppable braking power from durable, all-terrain compatible brakes.


Leader 24 kid bikes are designed to suit young riders and come with a stem, handlebar, Seatpost, and saddle.


Size: One size 320 mm

Colors: Deep Blue / Light Blue / Flame Red

TECH SPECS

DOWNLOAD USER MANUALS

COMPONENTS / TECHNICAL SPECIFICATIONS

Frame
Leader 24 7005 Custolite alloy, internal headset, replaceable hanger, BSA bottom bracket, QR 9mm rear axle

Sizes
One size 320mm

Rear shock
/

Shock setting
/

Fork
Suntour M3010 50mm, 25mm stanchions, soft spring. Settings: spring preload

Headset
CH-9280, Internal ZS, 44mm external diameter cup

Stem
MDK XC, alloy, 25.4mm barbore, rise: +/-7°, length: 60mm

Handlebar
MDK XC 1.0, 6061 alloy, rise: 25mm, width: 620mm, 9° backsweep, 5° upsweep, 25.4mm barbore

Grips
Onoff Diamond, 86mm

Seatpost
MDK XC, 6061 T6 alloy, diameter 27.2mm, length 300mm, offset 15mm

Saddle
Mondraker Leader Kids series

Front brake
Tektro Alloy V-Brake

Rear brake
Tektro Alloy V-Brake

Brake lever
Tektro 2-finger kids

Rim
MDK-24 Alloy, 32 spokes

Spokes
CN round stainless steel

Front hub
Formula OV31, 9x100mm QR axle, cup & cone ball bearings

Rear hub
Formula OV31, 9x135mm QR axle, cup & cone ball bearings

Front tyre
Kenda Small Block Eight 24x2.1, single compound, 30TPI, wire bead

Rear tyre
Kenda Small Block Eight 24x2.1, single compound, 30TPI, wire bead

Crank
Prowheel PRO, 152mm

Rings
36T

Bottom bracket
CH-52

Pedals
Wellgo LU-205

Chain
KCM Z-72

Front  derailleur
/

Rear derailleur
Shimano Altus M310, 8s

Lever
Shimano RS45 Revoshift, 8s

Sprocket
Sunrace CSM66, 11-34T, 8s

Hanger
Mondraker M069

Others
/

Weight without pedals
11.6 kg



MEASUREMENTS


MEASUREMENTS / GEOMETRY

  Frame size 24
A Seat Tube Lenght 320mm
B Top Tube Lenght 510mm
C Bottom Bracket Drop -30mm
D Bottom Bracket Height 280mm
E Chainstay Lenght 395mm
F Seat Tube Angle, Actual 71°
G Seat Tube Angle, Effective 71°
H Head Tube Angle 68°
I Fork Offset 40mm
J Wheelbase 964mm
K Head Tube Lenght 100mm
L Reach 340mm
M Stack 495mm
