Mondraker - NEVA 27.5 (WOMEN)

MOND-B-Neva-275-BlkGreen20-S

  • Sale
  • Regular price $999.00
  • Will be in stock after


PLEASE CALL US AT 805-850-3200 TO PLACE YOUR ORDER


DESCRIPTION

NOTE:

Pre-orders only. Subject approval to availability and delivery times.

Please call us for availability and all other information at 805-850-3400.


Experience the Neva difference in Cross-country rides and marathons! These stylish and modern XC bikes with race geometry, are also great for urban city riders and for those aspiring to enter the world of mountain biking.


Durable custolite alloy frame and HHG internal routing help with resistance and mobility for better speed and performance. The Neva is smartly designed with an internal headset and replaceable hanger.


XC Racers will love the safety and confidence offered by Mondraker’s avant geometry design. This race geometry also helps with improved handling, overall control, uphill precision, and stability in tough and technical terrains.


HHG Internal Cable Routing helps with a minimalistic, clean design. Neva XC bikes are race-ready with enhanced traction and momentum. The Neva has a high-performance suspension system that helps with stability and control by absorbing the strongest vibrations and keeping your wheels planted on the ground even on the bumpiest of the trails.


Neva XC Bike sports high-performance front and rear derailleurs and 27.5” tires, for ultimate precision and grip through uneven and rough trails. Extreme riders can conquer rigorous trails in the comfort of consistent and unstoppable braking power from durable, all-terrain compatible, MTB brakes.


Sizes: S: 330mm / M: 380mm / L: 430mm

Colors: Black / Light Green / Gum

TECH SPECS

DOWNLOAD USER MANUALS


COMPONENTS / TECHNICAL SPECIFICATIONS

Frame
Neva 27´5 6061 Custolite Alloy triple butted, Avant Geometry, internal headset, HHG internal cable routing, replaceable hanger, BSA bottom bracket, QR 9mm rear axle

Sizes
S: 330mm / M: 380mm / L: 430mm

Rear shock
/

Shock setting
/

Fork
Suntour XCT ATB RL 27´5 100mm, 28mm steel stanchions, 1-1/8” steerer tube, 9mm QR axle. Settings: spring preload, lockout

Headset
CH-9280, Internal ZS, 44mm external diameter cup

Stem
MDK XC, alloy, 31.8mm barbore, rise: +/-7°, length: sizes S/M: 60mm, size L: 75mm

Handlebar
MDK XC 1.0, 6061 alloy, rise: 25mm, width: 660mm, 9° backsweep, 5° upsweep, 31.8mm barbore

Grips
Onoff Ergo

Seatpost
MDK XC, 6061 T6 alloy, diameter 27.2mm, length 350mm, offset 15mm

Saddle
Mondraker Neva design

Front brake
Tektro HDM275 hydraulic, 160mm IS 6 bolts rotor

Rear brake
Tektro HDM275 hydraulic, 160mm IS 6 bolts rotor

Brake lever
Tektro HDM275 hydraulic

Rim
MDK-XS1 27´5, 24mm external width, 32 spokes

Spokes
CN round stainless steel

Front hub
MDK DC20, 9x100mm QR axle, cup & cone ball bearings, IS 6 bolts

Rear hub
MDK DC22, 9x135mm QR axle, cup & cone ball bearings, IS 6 bolts

Front tyre
Kenda Slant Six 27´5x2.35 single compound, 30TPI, wire bead

Rear tyre
Kenda Slant Six 27´5x2.35 single compound, 30TPI, wire bead

Crank
Shimano MT101-2, 2x9s, S/M size: 170mm, L size: 175mm

Rings
36T alloy / 22T steel

Bottom bracket
CH-52

Pedals
Wellgo LU-895DU

Chain
KMC Z99, 9s

Front  derailleur
Shimano Alivio FD-M4000, side swing, front pull

Rear derailleur
Shimano Acera RD-M3000, Shadow, SGS, 9s

Lever
Shimano Altus M2010, 2x9s

Sprocket
SunRace CSMS90, 11-34T, 9s

Hanger
Mondraker M072

Others
/

Weight without pedals
14.4 kg




MEASUREMENTS

MEASUREMENTS / GEOMETRY

  Frame size S M L
A Seat Tube Lenght 380mm 430mm 480mm
B Top Tube Lenght 535mm 555mm 580mm
C Bottom Bracket Drop -55mm -55mm -55mm
D Bottom Bracket Height 300mm 300mm 300mm
E Chainstay Lenght 425mm 425mm 425mm
F Seat Tube Angle, Actual 74° 74° 74°
G Seat Tube Angle, Effective 74° 74° 74°
H Head Tube Angle 68.5° 68.5° 68.5°
I Fork Offset 42mm 42mm 42mm
J Wheelbase 1042mm 1064mm 1090mm
K Head Tube Lenght 100mm 120mm 130mm
L Reach 366mm 380mm 403mm
M Stack 588mm 607mm 616mm
