Mondraker - Dusty XR Bike - Desert Grey / Orange / Carbon (e-MTB GRAVEL | 2023)

MOND-B-Dusty-XR-Carbon23-S

  • Sale
  • $12,799.00
  • Regular price $12,999.00
ZEITBIKE means FREE SHIPPING on orders over $99 😁👍🏼


Pre-Orders available at (805) 850-3200 or info@zeitbike.com


NOTE:
Pre-orders only. Subject approval to availability and delivery times.
Please call us for availability and all other information at 805-850-3200.

DESCRIPTION

SizesS: 440mm / M: 460mm / L: 500mm / XL: 530mm
Colors: Desert Grey / Orange / Carbon

DUSTY XR, our top-of-the-range model, features an SRAM FORCE ETAP AXS 1x12 drivetrain, Mavic Allroad Pro Carbon SL carbon wheels, 45mm Maxxis Rambler EXO tires, a 40mm-travel RockShox Rudy Ultimate fork, and a RockShox Reverb XPLR AXS seatpost offering 75mm of drop.

With gravel bike specific geometry and the philosophy that sets Mondraker apart from the rest, the DUSTY comes with that extra bit of fun that a motor brings to the mix so you can take your DUSTY down trails where logic tells you that you really shouldn’t.

That’s why Dusty XR has the Mahle X20 system, complete with its internal 350Wh battery. It’s the lightest and most sophisticated system in its class, and the integration is so on point it’ll be difficult for you to tell it’s electric.

SPECS

COMPONENTS / TECHNICAL SPECIFICATIONS

FRAME

Dusty Stealth Air Carbon, pressfit 386 EVO bottom bracket, tapered head tube, HHG internal cable routing, integrated internal non-removable battery, 12x142mm rear axle, 1X or 2X drivetrain design, Flatmount brake compatible, integrated dropout speed sensor.

SIZES

S: 440mm / M: 460mm / L: 500mm / XL: 530mm

FORK

RockShox Rudy Ultimate, 40mm travel, 12x100mm maxle stealth, 45mm offset

HEADSET

OnOff gravel tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

STEM

OnOff gravel 6061 T6 Alloy, 31.8mm barbore, rise: +/-7º, length: sizes S: 70mm M: 70mm, L: 80mm, XL: 90mm

HANDLEBAR

OnOff Barium gravel 18º bar flare. Width sizes S/M: 440mm, size L/XL: 460mm

GRIPS

Barium gravel dark grey

SEATPOST

RockShox Reverb XPLR AXS 75mm wireless 27.2X400mm dropper post

SADDLE

FIZIK Terra Argo X7 150mm

FRONT BRAKE

Sram Force Etap AXS 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

REAR BRAKE

Sram Force Etap AXS, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

BRAKE LEVER

Sram Force, contact point adjustment, tooled reach adjust, plastic levers

RIMS

Mavic Allroad Pro Carbon SL Disc, UST, 23mm internal width, hookless, 24 spokes

SPOKES

Mavic Steel double butted flat spokes

FRONT HUB

Mavic, 12x100mm, IS 6 bolts

REAR HUB

Mahle X20 Drive Unit, XDR freehub

FRONT TIRE

Maxxis Rambler 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead

REAR TIRE

Maxxis Rambler 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead

CRANKSET

Sram Force 1 Carbon GLS DUB Wide, S: 170mm, M: 172,5mm, L: 172,5mm XL: 175mm.

RINGS

Sram X-Sync Eagle 40T direct mount, alloy, narrow-wide,

BOTTOM BRACKET

Mahle DUB pressfit, sealed bearings, w/ torque sensor

PEDALS

-

CHAIN

Sram NX Eagle, 12s, Powerlock

FRONT DERAILLEUR

-

REAR DERAILLEUR

Sram  X01 Eagle AXS, Type 3 roller bearing clutch, cage lock, 1x12s

SHIFT LEVERS

Sram Force Etap AXS 12s, single click

CASSETTE

Sram XG-1275, 10-52T, 12s

MOTOR

Mahle X20 Drive Unit

BATTERY

Mahle X20 IX350Wh

DISPLAY

Pulsar One Wireless

DERAILLEUR HANGER

-

OTHERS

*Optional range extender: Mahle e185 , 172Wh

WEIGHT

13.8 kg



GEOMETRY

MEASUREMENTS / GEOMETRY(Click on image to expand)

Mondraker Dusty R Geometry

Size

S

M

L

XL

A

Seat Tube Length

440 mm

460 mm

500 mm

530 mm

B

Top Tube Length

550 mm

570 mm

595 mm

620 mm

C

Bottom Bracket Drop

70 mm

70 mm

70 mm

70 mm

D

Bottom Bracket Height

286 mm

286 mm

286 mm

286 mm

E

Chainstay Length

425 mm

425 mm

425 mm

425 mm

F

Seat Tube Angle, Actual

74º

74º

74º

74º

G

Seat Tube Angle, Effective

74º

74º

74º

74º

H

Head Tube Angle

70º

70º

70º

70º

I

Fork Offset

45 mm

45 mm

45 mm

45 mm

J

Wheelbase

1034 mm

1056 mm

1082 mm

1110 mm

K

Head Tube Length

125 mm

150 mm

175 mm

210 mm

L

Reach

393 m

405 mm

424 mm

440 mm

M

Stack

548 mm

576 mm

595 mm

628 mm

N Stem Length 60 mm 60 mm 70 mm 80 mm
O Fork Height 420 mm 420 mm 420 mm 420 mm

RESOURCES

Spare Parts
Suspension Setup

SIZE GUIDE

Bike Size Guide (Click on image to zoom in)
